We supply a wide range of Manual Valves and parts for Oilfield, Refinery, Petrochemical Plant, Marine and Industrial applications according to below standard specification for various pressure classes, sizes and applications.
Our specialist Valve team can supply a comprehensive range of manual valves covering Check, Gate, Ball, Butterfly, Plug and many others. We can offer Valves in many different materials ranging.
Standards: ANSI, ASME, API, BS, DIN, AFNOR, JIS, UNI, SIS, GOST
Materials: Carbon Steel, Low Temp CS, Stainless Steel, Chrome-Moly, Aluminum, Duplex, Alloy Steel, Inconel, Nickel Alloys, Hastelloys, Titanium
Grades: A216 WCB, A105, CF8/8M, LF2, 316, 316L, 304, 304L, 321, F11 to F91
Special Requirement: NACE MR 0175
Classes: 150, 300, 600, 800, 1500, 2000, 2500, 4500
Needle Valves
Size: ¼” to 1”
Class: 6000, 10000 PSI
Ends: Threaded, Socket Weld, Flanged & Butt Weld
Port: Reduced or Full
Bonnet: Bolted, Welded, Pressure Seal
Wedge: Solid or Flexible
Check Types: Piston, Swing, Ball, Wafer, Lug Globe Types: Flat, Tapered, Plug or Regulating Disc Angle
Plug Valves
Metal-Seated
ASME CLASS: 150- 1500
Sizes: 1/2’’ –36’’
DN: 15 - 900
Materials: Iron, Carbon Steel, Stainless Steel, Special Alloys, Alloy Steel
Connections: Flanged, Butt Weld, Threaded
Body Style: Special Configurations Available
Butterfly Valves
Sizes: 2” to 48”
Class: 150 to 2500
Types: Wafer, Lug, Center Flanged, Double Flanged
Check Valves
Sizes: ¼” to 2” Forged Body / Cast Body 2” to 36” Cast Body
Class: 800, 1500, 3000, (THDD & SW) 150 TO 2500 (FLANGED ENDS)
Ends: Threaded, Socket Weld, Flanged, & Butt Weld
Port: Reduced or Full
Bonnet: Bolted, Welded, Pressure Seal
Wedge: Solid or Flexible
Types: Piston, Swing, Ball, Wafer, Lug
Globe Valves
Sizes: ¼” to 2” Forged Body / Cast Body 2” to 36” Cast Body
Class: 800, 1500, 3000, (THDD & SW) 150 TO 2500 (FLANGED ENDS)
Ends: Threaded, Socket Weld, Flanged, & Butt Weld
Port: Reduced or Full
Bonnet: Bolted, Welded, Pressure Seal
Wedge: Solid or Flexible
Types: Flat, Tapered, Plug, or Regulating Disc Angle
Gate Valves
Sizes: ¼” to 2” Forged Body / Cast Body 2” to 36” Cast Body
Class: 800, 1500, 3000, (THDD & SW) 150 TO 2500 (FLANGED ENDS)
Ends: Threaded, Socket Weld, Flanged, & Butt Weld
Port: Reduced or Full
Bonnet: Bolted, Welded, Pressure Seal
Wedge: Solid or Flexible
Types: Slab, Knife, Pipe line API6D Gate
Ball Valves
Sizes: ¼” to 48” Cast/Forged Body
Class: 800, 2000, 2250, 3000, 5000 PSI (THDD & SW), 150 TO 2500 (FLANGED ENDS)
Ends: Threaded, Socket Weld, Flanged & Butt Weld.
Port: Regular & Full
Construction: Floating Ball, Trunnion Mounted, Side Entry, Top Entry
Types:
Manual Valves:
